IR-KIT HYBRID INFRARED SPRAY BOOTHS
Hybrid infrared curing with oil or gas fired heating for the spray cycle
The Eurotecno IR-KIT with technology derived from the top-of-the-range all electric Raptor spray booth, converts any Eurotecno automotive booth to a Hybrid Infrared Spray Booth. The IR-KIT can also be retro-fitted to upgrade existing spray booths.
The IR-KIT transforms a traditional spray booth into a Hybrid booth; Gas or oil powered heating for the spray cycle and Infrared curing. Hybrid booths can also use the burner for a traditional bake cycle.
Hybrid booths include a control panel that allows the operator to set the output power of the infrared lamps independently for the top and bottom rows. The operator can also choose which lamps to use during the curing cycle, significantly reducing energy consumption when only a part of the vehicle needs curing.
Infrared cure cycle timer
Power control. Independently set the power output of the upper rows of infrared lamps
Power control. Independently set the power output of the lower rows of infrared lamps
Independently switch on any combination of the five banks of infrared lamps
Indicators showing which banks of Infrared lamps are active
Any of our Automotive Spray Booths can be converted to hybrid operation with the addition of the IR-KIT. The Raptor spray booth is also available as fully electric or as a Hybrid.
Lower level Infra-Red lamps with glass cover to protect the IR tubes from paint — The cover is interlocked to prevent operation when closed.
High level infrared lamps each side; The lamps have independent power control for the upper and lower lamps.
The ceiling mounted infrared lamps are suspended from the roof and can be retrofitted to most Eurotecno spray booths
Additional lamps are installed in the front and end walls at high level.
Optional side extraction spray booth; The IR-KIT can be also be installed in booths with underfloor or end extraction.
